Planetary Gearbox Gear Ratio 27:1 Stepper Motor NEMA 17 L=48mm 1.68A

$30.00

In Stock:

50

Model: 42HB48-1684S-PG27

Weight: 0.6KG

Certificated: ISO, CE, RoHS

Brand: FRANKHUMOTOR

Ships From China

50 in stock (can be backordered)

NEMA 17 Geared Stepper Motor: This compact geared stepper motor has a frame size 42x48mm with rated current 1.68A, integrated with a economy planetary gearbox of gear ratio 27:1. It is specially designed for the robot but also can work for the applications that require high torque or low speed but limited space.

NEMA 17 Geared Stepper Motor Specification

  • Part Number: 42HB48-1684S-PG27
  • Step Angle: 1.8deg w/o gearbox
  • Bi/Unipolar: Bipolar
  • Holding Torque: 0.52Nm w/o gearbox
  • Rated Current/phase: 1.68A
  • Frame Size: 42x42mm
  • Motor Length: 48mm
  • Number of Leads: 4
  • Lead Length: 500mm
  • Gearbox Type: Planetary
  • Gear Ratio: 27:1
  • Efficiency: 80%
  • Backlash at No-load: 1.5degree
  • Gearbox Length: 36.8mm
  • Shaft Diameter: Φ8mm
  • Shaft Length: 20mm
  • D-cut Length: 15mm

Overall Size

NEMA 17 Geared Stepper Motor
