Size 42mm NEMA 17 Linear Actuator Stepper Motor Captive Type 60mm Stack Lead 12.7mm Travel 19.05mm

Size 42mm NEMA 17 Linear Actuator Stepper Motor Captive Type 60mm Stack Lead 12.7mm Travel 19.05mm

$85.00

In Stock:

5

Model: 42AI60-2504C-1905

Weight: 0.55KG

Certificated: ISO, CE, RoHS

Ships From China

5 in stock (can be backordered)

NEMA 17 Strong Linear Actuator Captive: This size 42mm model is a NEMA 17 Captive type screw linear actuator stepper motor with a 60mm body length, 1.8 degree step angle and 2.5A rated current. It is integrated with a Φ6.35mm diameter, 19.05mm stroke length, the linear travel is 12.7mm per revolution/0.0635mm per step. It has the characteristics of high performance, high thrust, long life, low noise and high efficiency.

NEMA 17 Strong Linear Actuator Captive Specification

NEMA 17 Strong Linear Actuator Captive

  • Part Number: 42AI60-2504C-1905
  • Motor Type: Captive
  • Step Angle: 1.8deg
  • Bi/Unipolar: Bipolar
  • Rated Current/phase: 2.5A
  • Driving Voltage: 12-24VDC
  • Frame Size: 42x42mm
  • Body Length: 60mm
  • Lead Travel: 19.05mm
  • Lead Screw Diameter: Φ6.35mm
  • Lead/Revolution: 12.7mm
  • Lead/Step: 0.0635mm
  • Number of Leads: 4
  • Lead Length: 500mm
  • Weight: 500g
  • Stepper Drive: FLKH2D1228DC

Overall Size

If you need a PDF data sheet, please send the email to: info@frankhumotor.com!
